Absima CR3.4 Crawler Landi RTR Limited Edition – Orange 12017

Description

Absima CR3.4 Crawler Landi RTR Limited Edition – Orange 12017

The CR3.4 LANDI Scale Crawler is a high-end car loaded with technical features which are unusual for a “ready-to-run” vehicle!

This limited edition comes in a fancy “ABS hard plastic body” with lots of moving parts like doors and engine hood.

In addition, attractive details such as light bowls, radiator grille, wipers, door handles and clear windows so that you can examine the wonderful interior.

Chassis and Suspension

A realistically designed 5mm CNC machined aluminum frame with a heavy-duty aluminum 4-link suspension system.
Our new oil-filled shocks with 3mm piston rods and outboard springs provide even a better and more realistic response. Tuning springs are also available in soft and hard (sold separately).
Portal Axles

Portal axles not only offer a greater distance from the differential housing to the ground than conventional axles, they also have another positive feature. In conventional crawlers, torque applies so much force that the vehicle “jumps” over the obstacle. The design of portal axles reduces the gear ratio at the wheels and virtually eliminates torque shocks from the drive. The overall reduction ratio of the axle drive is more than double that of non-portal designs to ensure a smooth running.

Steering System

A unique hydraulic steering shock absorber design combined with a 15kg digital and waterproof steering servo
hardened steel drive shafts and a 45.8° steering angle provide the best options for any terrain.
Drive System

The CR3.4 chassis has a 2-speed transmission that allows you to overcome difficult terrain and also quickly get to the next obstacle. Simply press a button on the remote control and change from gear ratio 1/37.1 (Low Speed) to 1/15.1 (High Speed)

Lock and unlock the front and rear differentials independently for maximum performance on the track, all remotely controlled with your remote and 2 built-in mini servos. Leave the differential unlocked for smooth hadling at high speeds. On technically challenging trails, you can lock the front differential, the rear differential, or even both to tackle extreme terrain.

An aluminum motor mount and adjustable slip clutch provide added protection in extreme conditions.

Hardened steel differential gears and drive parts – designed for high loads

Lighting System

As standard, the ABSIMA Landi comes with switchable headlights and taillights.
If you want to expand the lighting, no problem! All light shells are already mounted, so that nothing stands in the way of a separately available light unit.

CAR SPECS:

Length: 542mm
Width: 250mm
Height: 240mm
Ground Clearance: 53mm
Wheelbase: 313mm
Weight: 2970g
Approach Angle: 60°
Departure Angle: 45°
Steering Angle: 45.8°
Wheels: 12mm Hex Beadlock 1.9″ 32x69mm
Tires: 43x120mm
Shock Length: 90mm
Shock Oil Viscosity: 500cps
Transmission: 2-speed (Hi 1/15.1 / Lo 1/37.1), remote shifting
Gear Pitch: Module 0.8/32dp – Pinion 16Z / Spur Gear 44T
Drive System: 4WD
ELECTRONIC SPECS:

ESC: 60A Brushed/Waterproof with T-Plug (BEC 6V@3A, NiMh/LiPo suitable)
Motor: 600 high-torque brushed motor 21T
Steering Servo: 15kg MG, digital and waterproof
Mini Servos: 0,9kg, waterproof
Radio System: 6-channel 2.4GHz radio system (4.8 – 12.0V LiPo suitable)

INCLUDES:

Absima CR3.4 LANDI RTR Model
6-channel 2.4GHz Radio System
Manual (DE/EN/FR)
Required for Use

7.4v-11.1v LiPo Battery
Suitable LiPo Charger
4x AA Batteries
LiPo Safe Charge Bag (recommended)
